Q: What are the requirements for fire smoke walls?

Q: What are the requirements for fire smoke walls?

2 years, 2 months ago

(Note: This is Part 1 of a series; Part 2 is here; Part 3 is here)

A: The two building codes that would be applicable for most healthcare facilities are the International Building Code, which would be adopted by the local authority having jurisdiction or the state, and the 2012 NFPA 101 Life Safety Code, which has been adopted by Centers for Medicare and Medicaid Services (CMS). The terminology and requirements for fire rated construction varies slightly between the two codes. Below is a summarization of the types of fire and smoke rated construction and their application.

Comparing the requirements of the International Building Code and NFPA 101 Life Safety Code for fire-rated construction in healthcare facilities:

International Building Code

Fire Wall

Summary: A fire-resistance-rated wall that restricts the spread of fire; Extends continuously from the foundation to/through the roof; has sufficient structural stability under fire conditions to allow collapse of construction on either side without collapse of the wall; Openings are protected.

Uses: Creates separate buildings in the eyes of the code.

Fire Barrier

Summary: A fire-resistance-rated wall assembly designed to restrict the spread of fire in which continuity is maintained; Openings are protected;

Uses: Separates vertical exit enclosures; Occupancies; Fire areas; Incidental uses (if sprinkler exceptions not applicable)

Fire Partition

Summary: A vertical assembly designed to restrict the spread of fire; openings are protected;

Uses: Corridor walls; Separate elevator lobbies

Smoke Barrier

Summary: A continuous membrane (vertical or horizontal) designed and constructed to restrict the movement of smoke; Minimum of one hour fire rating.

Uses: Openings are protected; Enclose smoke compartments

Smoke Partition

Summary: A wall assembly designed and constructed to limit the movement of smoke; Does not require a fire rating; Openings are protected; Not required to be continuous through concealed spaces/ceiling;

Uses: Corridors in Group I-2 occupancies (hospitals, nursing homes); Separate elevator lobbies in sprinklered buildings

NFPA 101 Life Safety Code

Fire Wall

Summary: A wall separating buildings or subdividing a building to prevent the spread of fire and having a fire resistance rating and structural stability; Openings are protected.

Uses: Creates separate buildings in the eyes of the code.

Fire Barrier

Summary: A continuous membrane that is designed and constructed with a specified fire resistance rating to limit the spread of fire, that also restricts the movement of smoke; Membrane openings are protected.

Uses: Separates Occupancies; Hazardous areas; Horizontal exits; Exit enclosures; Shaft enclosures

Fire Partition

Summary: Not defined.

Smoke Barrier

Summary: A continuous membrane designed and constructed to restrict the movement of smoke; Membrane openings are protected; Minimum of one hour fire rating.

Uses: Enclose smoke compartments; Separate elevator lobbies; Separate cooking facilities in some applications

Smoke Partition

Summary: A continuous membrane that is designed to form a barrier to limit the transfer of smoke; Does not require a fire rating; Membrane openings are protected

Uses: Separate sprinkler protected hazardous areas
